Deskripsi
Spesifikasi :
Bore (mm) 150
Accuracy Standard : ±0.5%
Optional : ±0.2%
Flow Range
2 – 5mPa•s
Diesel, Light Oil
15 – 180 m³/h
Flow Range
5 ̴ 150mPa•s
Diesel, Light Oil
8 – 180 m³/h
Max. Working
Pressure
10 kgf/cm²
Hydraulic Test
Pressure
20 kgf/cm²
Max. Working
Temperature
Standard : 80°C
Optional : 150°C
Flange Rating JIS 10 kgf/cm² FF
Material – Body Cast Iron
Material – Rotor Cast Iron
Counter Unit Totalizing counter (7 Digits)
Reset counter (5 Digits)
Flow Direction Right → Left
